Description

UniFi Switch Pro 24 PoE (USW-Pro-24-PoE): Managed L3 24-Port (8× PoE++, 16× PoE+) Switch with Dual 10G SFP+, 400W Power Budget, Touch LCM, and Redundant Power Support

The Ubiquiti UniFi Switch Pro 24 PoE (USW-Pro-24-PoE) is a professional-grade Layer 3 managed switch designed for modern enterprise networks that demand high performance, advanced PoE capabilities, and robust reliability.
Featuring 24× Gigabit RJ45 ports — 8× PoE++ (up to 60W) and 16× PoE+ (up to 32W) — along with 2× 10G SFP+ uplinks, the switch delivers a total PoE power budget of 400W, making it ideal for powering WiFi 6/7 Access Points, PTZ cameras, VoIP phones, and AV-over-IP systems.

High-Performance Layer 3 Switching for Enterprise Networks

The USW-Pro-24-PoE combines high-density connectivity, advanced power delivery, and Layer 3 routing intelligence within a compact 1U rackmount design. It supports inter-VLAN routing, DHCP server/relay, and static routing, optimizing traffic flow and network segmentation across complex infrastructures.

Its 1.3” color LCM touchscreen provides at-a-glance system status, while centralized management via UniFi Network allows administrators to monitor, configure, and automate the entire UniFi ecosystem through an intuitive interface.
With redundant power support via USP-RPS, it ensures continuous uptime even in the event of power supply failure — critical for mission-dependent installations.

Key Features

⚙️ Enterprise-Grade Layer 3 Functionality

Supports inter-VLAN routing, static routing, and DHCP server/relay, enabling advanced traffic segmentation, optimized subnet communication, and simplified IP management.

🔌 Advanced PoE Power Delivery

• 8× PoE++ ports (802.3bt Type 3) — up to 60W per port for power-hungry devices like PTZ cameras or UniFi U7 Pro APs.

• 16× PoE+ ports (802.3at) — up to 32W per port for standard UniFi devices.

• 400W total PoE power budget ensures reliable operation across all connected devices.

🌐 High-Speed 10G Fiber Uplinks

Equipped with 2× 10G SFP+ ports, allowing for high-bandwidth uplinks to aggregation or core switches, ensuring smooth traffic flow even in large or data-intensive deployments.

🔋 Redundant Power-Ready

Compatible with the USP-RPS (UniFi SmartPower Redundant Power System), providing automatic failover protection in case of power loss.

📊 Integrated Touchscreen Display

A 1.3” color LCM touchscreen gives immediate insight into port utilization, system health, and power consumption, reducing the need for external monitoring tools.

Technical Specifications

General & Ports

• Ethernet Ports: 24× RJ45 Gigabit (10/100/1000 Mbps)

  • 8× PoE++ (up to 60W per port, 802.3bt)

  • 16× PoE+ (up to 32W per port, 802.3at)

• SFP+ Uplinks: 2× 10G

• Total PoE Budget: 400W

• Form Factor: 1U Rackmount

Performance

• Switching Capacity: 88 Gbps

• Non-Blocking Throughput: 44 Gbps

• Forwarding Rate: 65 Mpps

• MAC Address Table: 16,000 entries

Layer 3 Features

• Inter-VLAN Routing

• Static Routing

• DHCP Server/Relay

• QoS & VLAN Support

• Optimized for Enterprise and AV-over-IP

Power & Reliability

• Power Input: 100–240V AC, 50/60 Hz

• Internal PSU: 450W AC/DC

• Power Consumption:

  • Up to 400W with PoE active

  • ~40W without PoE

• Redundant Power: Supported (USP-RPS connection)

Display & Management

• Display: 1.3” color LCM touchscreen

• Management: UniFi Network (web/app), Ethernet, AR (Augmented Reality)

Environment & Certifications

• Operating Temperature: -5 to 45 °C

• Humidity: 10–90% (non-condensing)

• Certifications: CE, FCC, IC, Anatel

• NDAA Compliant: Yes

Mechanical

• Dimensions: 442 × 285 × 44 mm

• Weight: 4.3 kg (approx.)

• Cooling: Quiet active fans

Ideal For

• Enterprise networks: Layer 3 performance, advanced PoE, and 10G uplinks in one unified switch.

• WiFi 6/7 Deployments: Power multiple high-performance UniFi APs with PoE++ support.

• Video Surveillance Systems: Perfect for powering UniFi Protect cameras, including PTZ models.

• AV-over-IP and Smart Buildings: Designed for Dante, NDI, and other high-bandwidth PoE-powered systems.

• Mission-Critical Environments: Redundant power-ready with USP-RPS for uninterrupted operation.
