UniFi Switch Pro 24 (USW-Pro-24): Managed L3 24-Port (2× 10G SFP+) Switch with LCM Display, Silent Operation & Redundant Power Support

The Ubiquiti UniFi Switch Pro 24 (USW-Pro-24) is a professional Layer 3 managed switch engineered for enterprise environments that demand high performance, silent operation, and advanced reliability. Featuring 24× Gigabit Ethernet ports and 2× 10G SFP+ uplinks, it delivers powerful switching and routing capabilities with seamless integration into the UniFi Network platform.

Designed with a fanless cooling system, the USW-Pro-24 operates in complete silence, making it ideal for open offices, studios, and mission-critical environments where noise must be minimized. With redundant power support via USP-RPS, it ensures continuous operation even during power failures.

Enterprise-Grade Switching with Total Silence

The USW-Pro-24 combines high-capacity Layer 2 and Layer 3 functionality in a compact 1U rackmount design. It supports inter-VLAN routing, static routing, and DHCP services, allowing intelligent traffic distribution across large networks.
Optimized profiles for Pro AV protocols such as Dante and NDI make it perfect for audio/video-over-IP applications requiring ultra-low latency and precise synchronization.

Key Features

⚙️ High-Performance Layer 3 Switching

• Supports inter-VLAN routing, static routing, and DHCP server functionality.

• Enables efficient internal traffic segmentation and optimized routing across subnets.

🔇 Completely Silent Operation (Fanless Design)

• Operates with zero fan noise, ideal for offices, studios, classrooms, and meeting rooms.

• Maintains high reliability and energy efficiency through passive cooling.

🌐 10G SFP+ Uplinks

• Equipped with 2× 10G SFP+ ports for high-speed fiber uplinks or aggregation, ensuring smooth connectivity to core switches or data centers.

🧩 Redundant Power Ready

• Supports redundant power via USP-RPS (UniFi SmartPower Redundant Power System) to prevent downtime during power supply failure.

📊 Integrated 1.3” Touchscreen Display

• Full-color LCM touchscreen for quick port and system status monitoring, diagnostics, and real-time alerts.

🧠 Pro AV Optimization

• Pre-tuned for Dante, NDI, and other professional AV-over-IP standards.

• Ensures stable, low-latency streaming performance in complex AV environments.

Technical Specifications

Mechanical & Ports

• Dimensions: 442 × 285 × 44 mm

• Weight (with brackets): 3.6 kg

• Form Factor: 1U Rackmount

• Ethernet Ports: 24× RJ45 Gigabit (1G)

• SFP+ Ports: 2× 10G

Performance

• Switching Capacity: 88 Gbps

• Non-Blocking Throughput: 44 Gbps

• Forwarding Rate: 65 Mpps

• MAC Address Table: 16,000 entries

Power & Hardware

• Max Power Consumption: 30W

• Power Input: Universal AC (100–240V, 50/60 Hz)

• Redundant Power: DC input for USP-RPS

• Internal PSU: 36W AC/DC

Layer 3 Features

• Inter-VLAN Routing

• Static Routing

• DHCP Server

• Pro AV Profiles (Dante, NDI, etc.)

Management & Interface

• Management: UniFi Network (Web/Mobile), Ethernet, AR (Augmented Reality via UniFi App)

• Display: 1.3” Color LCM Touchscreen

Environment & Certifications

• Operating Temperature: -5 to 45 °C

• NDAA Compliant: Yes

• Certifications: CE, FCC, IC, Anatel

Ideal For

• Enterprise and Corporate Networks: High-performance core or distribution switching with silent operation.

• Studios and AV Installations: Optimized for Dante and NDI with ultra-low latency.

• Mission-Critical Environments: Redundant power-ready design ensures uninterrupted uptime.

• Offices and Educational Spaces: Quiet, efficient, and reliable Layer 3 switching in a compact form factor.
