UniFi Switch Flex 2.5G 8 PoE (USW-FLEX-2.5G-8-POE): Compact Managed L2 Switch with 8× 2.5GbE PoE++ and Dual 10G Uplinks

The Ubiquiti UniFi Switch Flex 2.5G 8 PoE (USW-FLEX-2.5G-8-POE) combines multi-gigabit performance with powerful PoE++ delivery in a compact and flexible form factor. Featuring eight 2.5GbE RJ45 ports, all supporting PoE++ (802.3bt, up to 64W per port), and dual 10GbE uplinks (1× RJ45 + 1× SFP+), this switch is ideal for powering and connecting WiFi 6/7 Access Points, 4K/8K IP cameras, control panels, or high-end VoIP systems — all through a single device.

⚡ Multi-Gigabit Speed Meets High-Power PoE++

Deliver both bandwidth and power where it’s needed most.
All eight 2.5GbE ports support PoE++ up to 64W per port, enabling seamless deployment of power-hungry devices such as:

• WiFi 6/7 Access Points

• UniFi Protect PTZ cameras

• AV-over-IP and digital signage systems

• High-performance VoIP and automation devices

🔌 Dual 10G Uplinks (RJ45 + SFP+)

The USW-FLEX-2.5G-8-POE includes both a 10GbE RJ45 uplink (which can also act as PoE In) and a 10G SFP+ fiber uplink, offering maximum flexibility for core connectivity — whether via copper or fiber backhaul.

⚙️ Flexible Powering Options

Choose the best power method for your installation:

• PoE+++ Input (10GbE RJ45 port): up to 76W PoE budget

• Optional 210W AC Adapter: unlocks full 196W PoE power across all ports

• PoE+ or PoE++ Input: economical options for smaller setups (16–46W PoE budget)

This flexibility allows the switch to scale from desktop PoE distribution to professional-grade multi-device deployments.

🧩 Compact, Silent, and Ultra-Versatile Installation

With its fanless design and compact Flex chassis, the switch can be installed anywhere — on a desk, wall, DIN rail, or magnetic surface (mounting accessories optional).
Perfect for offices, technical rooms, studios, or smart homes.

🧠 Centralized Management with UniFi Network

Managed via the UniFi Network Controller (v9.0.114 or later), the USW-FLEX-2.5G-8-POE provides full Layer 2 functionality:

• VLANs (802.1Q)

• STP/RSTP

• LACP (Link Aggregation)

• Port Mirroring & Isolation

• Access Control Lists (MAC/IP)

• Flow and Storm Control

• QoS prioritization

Everything is configurable and monitored through the intuitive UniFi web or mobile interface.

Technical Specifications

Interfaces

• 8× 2.5GbE RJ45 ports (PoE++ 802.3bt, up to 64W each)

• 1× 10GbE RJ45 (PoE+/PoE++/PoE+++ In)

• 1× 10G SFP+ uplink

• Management: Ethernet / UniFi Network

Performance

• Switching Capacity: 80 Gbps

• Non-Blocking Throughput: 40 Gbps

• Forwarding Rate: 59.5 Mpps

• MAC Address Table: 16,000 entries

• Layer: Managed Layer 2

Power

• PoE Output: 8× PoE++ (up to 64W/port, total up to 196W)

• Power Input Options:

  • PoE+++/PoE++/PoE+ In (via 10GbE RJ45 port)

  • Optional 210W AC adapter (included in some bundles)

• Max Power Consumption: 20W (switch only) / up to 210W with full PoE load

Mechanical & Environmental

• Dimensions: 204 × 90 × 31 mm

• Weight: 540 g

• Cooling: Passive (fanless)

• Mounting: Desktop, wall, DIN rail, magnetic (accessories optional)

• Operating Temperature: 0 to 40 °C

• Humidity: 10–90% (non-condensing)

Certifications

• CE, FCC, IC

• NDAA Compliant: Yes

Ideal For

• High-Density WiFi Deployments: Power multiple WiFi 6/7 APs at 2.5GbE.

• Professional AV & Surveillance: Support 4K/8K IP cameras, AV-over-IP systems, and control panels.

• SMBs & Creative Studios: Ultra-fast multi-gig connectivity with centralized management.

• Power Users & Integrators: Compact, flexible, and future-ready switch for demanding installations.
